IoT: Based on SE, HED offers a secure computing and storage environment. SE provides a secure trust root for the operators of IoT devices who issue the device ID number and certificate key in SE, combined with the security cloud on the cloud, form a complete set of IoT security solutions for trustable identity authentication, reliable communication encryption, data tamper-proof, and anti-repudiation to help safeguard the growth of IoT device operators' businesses.
| Product name | Capacity | RAM | Interface | Algorithm | Operating voltage | Operating temperature | Software version | Packaging | Packing | MPQ | Application field |
| CIU51_A Series | 32KB | —— | 7816 | DES/3DES | 1.62~5.5V | -25~85°C | 2892/2893/2894 | SOP8 | Tube | 10K | Highway Dual-chip OBE-SAM |
| CIU98_A Series | 144KB | —— | 7816/SPI/I2C/UART | DES/3DES AES/RSA/ECC SM1/SM2/SM3 SM4/SM9/SHA_n |
2.7～5.5V | -25~85°C | 2872 | QFN32 (4*4*0.75) | Reel | 3K | Smart Door Lock Smart Home Intelligent Meter Network Authentication |
| CIU98_B Series | 256KB/700KB | —— | 7816/SPI/I2C | 3DES/AES/RSA/ECC SM1/SM2/SM3 SM4/SHA_n |
1.62~5.5V | -40~105℃ -40~125℃ |
2955/3162 3184/3382/34D0 |
SOP8 (150mil) QFN32 (5*5) |
Reel Tube |
3K 10K |
Digital Key Side SE Automotive Electronics OBE-SAM T-BOX C-V2X Gateway |
| CIU98_D Series | 4.5KB/8KB/78KB | 9.5KB | 7816/SPI/I2C GPIO/1WI |
DES/3DES/AES HMAC/SHA256 ECC/SM2/SM3 SM4/SHA_n |
1.62～5.5V | -40~85°C | 0000/2782 2792/3222/3232 |
DFN8 (2*3) SOP8 |
Reel Tube |
3K 10K |
IoT Anti-counterfeiting Authentication Property Rights Protection Online Authentication |
| CIU98_E Series | PC EEPROM:224KB PROM:420KB 32KB |
16KB | 7816/14443/GPIO | DES/3DES/RSA SHA-n /SM1/SM2 SM3/SM4/SSF33 |
1.62~5.5V | -25~85°C | 0000/2422/2970 | SOP8 QFN32（4*4） |
Reel Tube |
3K 10K |
Secure Payments Identity Authentication Wearable Financial Social Security Transportation Intelligent Meter |
| CIU98_G Series | 32KB/90KB | —— | 7816/I2C/14443/GPIO | 3DES/AES RSA/ECC/ SM2 SM3/SM4/SHA_n |
1.62~5.5V | -25~85℃ | 3481/33C1 | DFN8(5*6)/QFN32 (4*4) | Reel | 3K | Highway CPC Digital Key Side SE Fob key SE |
| CIU98_H series | 200KB/256KB/512KB | 128KB | SPI/I2C/UART/USB/SD | 3DES/AES RSA/ECC/SHA-n SM2/SM3/SM4 |
1.62~5.5V | -40~85°C -40~105°C |
0000/3343/3343 | QFN32(5*5) | Reel | 3K | C-V2X Intelligent Cockpit Intelligent Driving and Other Domain Control High-speed Stream Encryption |
| CIU9872B_01 | 90KB | —— | 14443 | 3DES/AES RSA/ECC SM2/SM3 SM4/SHA_n |
1.62~5.5V | -40~85℃ | 33C0 | Non-connected Module | - | - | Digital Key NFC Card Key |
